    System Integration Solution

    We provide ISP, ICT, FCT systems that are an integrated full in-line solution
    for flash programming and PCBA testing

          OPTEEQ

          3x Faster Programming

          Next-gen Opteeq engine, up to 3x speed vs. previous generation

          4 Independent Channels

          Program different chips simultaneously, mixed interfaces in parallel

          Scale up to 32 Chips

          Module + HUB expansion, ideal for ATE and mass production

          Universal Interface Support

          JTAG, SWD, SPI, I2C, UART + CAN / CAN-FD / single-wire JTAG via adapters

          Single-Cable PoE Power

          Simplified wiring, effortless automation line integration

          Compact & Isolated

          161 x 86 x 30mm chassis with superior electrical isolation, built for ATE embedding

          Multi-Chip Mass Production

          Simultaneous programming of diverse chips — automotive lighting, motor controllers, and more

          Offline Mode Ready

          Standalone programming without PC or network, deploy anywhere instantly

          View Gallery

          OPTEEQ Universal Programmer

          Multi-Chip, Multi-Interface, Multi-Vendor Support
          Wide Chip & Interface Coverage

          Simultaneous programming of different chips per channel (mixed-type production support)

          Integrated support for standard ISP interfaces (JTAG, SWD, SPI, I2C, UART)

          Programmable channel I/O voltage: 1.6V to 5.5V

          Automotive-Specialized Chip Support

          CAN / CAN-FD protocol adapter modules

          Single-wire JTAG and differential signal conversion adapters

          Infineon TLE49XX Hall sensor support (EEPROM, TPO, self-calibration)

          Major automotive IC vendor support: Renesas, NXP, Infineon, Melexis, Elmos, ISSI, Nuvoton, and more

          Rapid New-Chip Algorithm Development

          Timely programming algorithm support for newly released chips

          Eliminates a key bottleneck during production ramp-up (unsupported new chips)


          ATE Integration & Flexible Production Deployment

          Compact, Scalable, Deploy-Anywhere Gang Programmer
          Optimized for ATE Embedded Integration

          Ultra-compact 161 x 86 x 30mm chassis for easy in-equipment mounting

          Single-cable power delivery via PoE (Power over Ethernet) — flexible, safe, and reliable wiring

          Superior electrical isolation from the external environment

          Scalable Mass Production Line Configuration

          Four fully independent channels

          Scale up to 32 channels with programmer module + HUB combination

          Ideal for diverse mass production — automotive lighting controllers, small motor controllers, and more

          PC / Network-Free Offline Operation

          Optional dedicated offline programming component — instant on-site deployment without PC or network

          Cost-effective for small-batch and trial production

          Dual license system (Device License + Channel License)
